Features

• Fully air operated.
• 2 ball piston design provides uniform positive displacement.
• Extremely durable pump with long life packing.
• Specially designed piston seals do not come into contact with material pumped. Hence, a longer life span as it is able to handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

Typical Applications

• For standard 55 gallons steel drum
• Foam chemical supply
• Spray gun supply
• Dispensing valve supply
• Cleaning chemical supply
• Fluid transfer

Typical Fluids Handled

• Solvent based paints
• Water based paints (SST models)
• Solvents
• Cleaning chemical supply
• Chemicals
• Catalysts
• Isocyanates
• Adhesives
• Resins
• Polyurethanes
• Polyureas

Technical Information

Fluid Ratio: 2:1
Max Output Flow Int: 7.5 gpm(28.4 lpm)
Max Output Flow Cont: 5.0 gpm(18.9 Ipm)
Max Output Pressure: 360 psi (24.8 bar)
Max Air Input Pressure: 180 psi (12.4 bar)
Air Inlet Port: 1/4 npt(f)
Fluid Outlet Port: 3/4 npt(f)
Rod Piston Packings: UHMU PE or Telfon®
Other Seals: Viton®
Rod Cylinder: Stainless Steel
Other Wetted Parts: Stainless Steel
Weight: 24 Ibs.(11.8 Kg.)
Package: 6"x6"x58" (152mmx152mmx147cm) 26 Ibs.(11.8 Kg.)
